MICRO VERSI X1

Product Overview

A Double Conversion, Rack Tower versatile UPS. Available in 1500, 3000, 6000 and 10000 W. The 1500 and 3000W have internal batteries and the facility to connect battery extension moduled for additional autonomy.

The 6 and 10kW UPS power modules are a high power density 2U (88.9mm) with the battery extension modules measuring 3U (133mm).

Enquire now

Key Features

Energy
Efficient

Unlocked
software

2 year
warranty

Unique features

The MICRO VERSI X1 is highly versatile UPS with unity power factor and can be installed as a floor standing tower UPS or in a 19-inch communications rack.

Design

Metartec have designed the MICRO VERSI X1 in a convertible form design in a compact 2U frame

Expandability

The MICRO VERSI X1 is scalable and can be connected with accessories to increase power availability. Up to three MICRO VERSI 6000 and 10000 can be connected in parallel.

Documentation

MICRO VERSI X1 Range

Product Specifications

1500 X1

Download datasheet

Run time for load

0.8

Max capacity used 50%

Capacity kW

1.5

Input

Voltage

200 / 208 / 220 / 230 / 240 VAC

Voltage Range

110-300 VAC ± 5% at 50% load or 160-300 VAC ± 5 % at 100% Load

Frequency range

47.5Hz ~ 52.5Hz or 57Hz ~ 63Hz

Input current THDi*

≤ 5% @ nominal input voltage

Power factor

≥ 0.99 @ Nominal Voltage (100% Load)

Output

Output voltage

200 / 208 / 220 / 230 / 240 VAC

Voltage regulation

± 1%

THDu

≤ 2% THD (Linear Load) ≤ 4% THD (Non-linear Load)

Frequency range

50Hz or 60Hz ± 0.1 Hz

Overload capacity

100% ~ 110% 10 Min / 110% ~ 130% 1 Min / >130% 1 Sec

Battery

Voltage

4 1.1 VDC ± 1%

Typical Charging Time

3 Hours to 95% capacity for internal battery @2A charging current

Charging Current

2A to 8A selectable on front LCD display

System

Efficiency

≥89% with fully charged battery

Relative humidity

20-90% RH @ 0 - 40°C (non-condensing)

Noise

Less than 50dB @ 1m

Dimensions

Weight kg

20.1

Width mm

483

Depth mm

410

Height mm

3000 X1

Download datasheet

Run time for load

0.8

Max capacity used 50%

Capacity kW

Input

Voltage

200 / 208 / 220 / 230 / 240 VAC

Voltage Range

110-300 VAC ± 5% at 50% load or 160-300 VAC ± 5 % at 100% Load

Frequency range

47.5Hz ~ 52.5Hz or 57Hz ~ 63Hz

Input current THDi*

≤ 5% @ nominal input voltage

Power factor

≥ 0.99 @ Nominal Voltage (100% Load)

Output

Output voltage

200 / 208 / 220 / 230 / 240 VAC

Voltage regulation

± 1%

THDu

≤ 2% THD (Linear Load) ≤ 4% THD (Non-linear Load)

Frequency range

50Hz or 60Hz ± 0.1 Hz

Overload capacity

100% ~ 110% 10 Min / 110% ~ 130% 1 Min / >130% 1 Sec

Battery

Voltage

82.1 VDC ± 1%

Typical Charging Time

3 Hours to 95% capacity for internal battery @2A charging current

Charging Current

2A to 8A selectable on front LCD display

System

Efficiency

≥91% with fully charged battery

Relative humidity

20-90% RH @ 0 - 40°C (non-condensing)

Noise

Less than 50dB @ 1m

Dimensions

Weight kg

30.4

Width mm

483

Depth mm

630

Height mm

6000 X1

Download datasheet

Run time for load

0.8

Max capacity used 50%

Capacity kW

Input

Voltage

200 / 208 / 220 / 230 / 240 VAC

Voltage Range

110-300 VAC ± 3 % at 50% load or 176-300 VAC ± 3 % at 100% Load

Frequency range

46Hz ~ 54Hz or 56Hz ~ 64Hz

Input current THDi*

≤ 4% @ nominal input voltage

Power factor

≥ 0.99 @ Nominal Voltage (100% Load)

Output

Output voltage

208 / 220 / 230 / 240 VAC

Voltage regulation

± 1%

THDu

≤ 1% THD (Linear Load) ≤ 4% THD (Non-linear Load)

Frequency range

50Hz or 60Hz ± 0.1 Hz

Overload capacity

100% ~ 110% 10 Min / 110% ~ 130% 1 Min / >130% 1 Sec

Battery

Voltage

(13.65 VDC x battery number) ± 1%

Typical Charging Time

9 Hours to 90% capacity for internal battery

Charging Current

4A selectable on front LCD display

System

Efficiency

≥94% with fully charged battery

Relative humidity

20-90% RH @ 0 - 40°C (non-condensing)

Noise

Less than 55dB @ 1m

Dimensions

Weight kg

Width mm

483

Depth mm

610

Height mm

10000 X1

Download datasheet

Run time for load

0.8

Max capacity used 50%

Capacity kW

Input

Voltage

200 / 208 / 220 / 230 / 240 VAC

Voltage Range

110-300 VAC ± 3 % at 50% load or 176-300 VAC ± 3 % at 100% Load

Frequency range

46Hz ~ 54Hz or 56Hz ~ 64Hz

Input current THDi*

≤ 4% @ nominal input voltage

Power factor

≥ 0.99 @ Nominal Voltage (100% Load)

Output

Output voltage

208 / 220 / 230 / 240 VAC

Voltage regulation

± 1%

THDu

≤ 1% THD (Linear Load) ≤ 4% THD (Non-linear Load)

Frequency range

50Hz or 60Hz ± 0.1 Hz

Overload capacity

100% ~ 110% 10 Min / 110% ~ 130% 1 Min / >130% 1 Sec

Battery

Voltage

(13.65 VDC x battery number) ± 1%

Typical Charging Time

9 Hours to 90% capacity for internal battery

Charging Current

4A selectable on front LCD display

System

Efficiency

≥94% with fully charged battery

Relative humidity

20-90% RH @ 0 - 40°C (non-condensing)

Noise

Less than 58dB @ 1m

Dimensions

Weight kg

Width mm

483

Depth mm

610

Height mm
